4channel HIGH-END power-amplifier with Full-Mosfet technology Burr-Brown pre-amplifier,
continuously independent temperature fancooling, efficient analog amplifier, very high efficiency,
Power RMS (4 Ohms), W: 4 x 175
Power RMS (2 Ohms), W: 4 x 255
Power RMS (2 Ohm / Bridge), W: 2 x 1000
Frequency range, Hz: 10 – 110000
KGI,%: 90
Split channels, dB: 75
Input sensitivity, V: 0.2 – 8
Crossover modes: HPF On / Off, LPF On / Off
The filter of HF channels 1-2: 35 – 175 Hz / 1400 – 7000 Hz, 12 dB / oct.
Filter low-pass channels 1-2: 50 – 300 Hz, 12 dB / oct.
HF channel filter 3-4: 35 – 250 Hz, 12/24 (for Mono mode) dB
Low pass filter 3-4: 50 – 300 Hz / 1000 – 6000 Hz, 12/24 (for Mono mode) dB
Rotation of the phase of channels 3-4 (for Mono mode), °: 0 – 360
RCA inputs
Remote level control: optional RTC HX
Switches of the operating mode of the inputs “Direct Input”
Switch operating mode inputs “2/4 channel”
Input mode switch for channels 3-4 “Mono / Stereo”
Protection against overvoltage, short-circuits of outputs, overheating
Supply voltage, V: 10 – 16
Fuse, A: 200 (external)
Dimensions, mm: 596 x 53 x 240
