Gain classes: A (channels 1-2), AB (channels 3-4), D (channel 5)
Power (CEA-2006, RMS, 14.4 V, 4 Ohm, THD+N < 1%): 2x50 + 2x120 + 1x500 W
Power (RMS, 14.4 V, 4 Ohm, THD+N < 1%): 2x75 + 2x140 + 1x600 W (4 Ohm)
Power (RMS, 14.4 V, 4 Ohm, THD+N < 1%): 2x75 (4 Ohm) + 2x140 (4 Ohm) + 1x1000 W (2 Ohm)
Power (RMS, 14.4 V, 4 Ohm, THD+N < 1%): 2x75 (4 Ohm) + 2x250 (2 Ohm) + 1x1000 W (2 Ohm)
Frequency range (-3 dB): 4-60000 Hz (channels 1-4) and 7-350 Hz (channel 5)
Signal-to-noise ratio (1 V, A-weighting): 100 dB (channels 1-4) and 87 dB (channel 5)
Signal-to-noise ratio (CEA-2006, rel. 1 W output): 80 dBA (channels 1-4) and 78 dBA (channel 5)
Harmonic Distortion (1 kHz, 4 ohms): 0.05% (channels 1-4)
Harmonic Distortion (100 Hz, 4 ohms): 0.3% (5 channels)
Dumping factor (1 kHz, 4 ohms): 100 (channels 1-4)
Dumping factor (100 Hz, 4 ohms): 80 (channel 5)
Line Level Input Sensitivity (RMS): 0.3-5.0 V
Line level input impedance: 15 kOhm
High level input sensitivity: 1.4 - 24 V
High Level Input Impedance: 5 kOhm
Line outputs (not affected by crossover): 1 pair
Crossover (channels 1-2): switchable, high-pass filter 50-500 or 500-5000 Hz, 12 dB/oct
Crossover (channels 3-4): switchable, high-pass filter 50-1000 Hz, 12 dB/oct, or PF 50-5000 Hz, 12 dB/oct
Crossover (channel 5): switchable, low-pass filter 50-150 Hz, 24 dB/oct.
Remote control (bass level adjustment for channel 5): VCRA (optional)
Additional modules: AV bit IN (optional)
Acceptable power cable size: 2 AWG (35 sq. mm)
Fuse rating: 100 A
Overall dimensions (LxWxH): 470x220x58 mm
Weight: 7.2 kgdl
