RMS power (4 Ohms), W: 4 x 150
RMS power (2 Ohms), W: 4 x 220
RMS power (4 Ohm / bridge), W: 2 x 440
Frequency range, Hz: 10 - 80000
OIG,%: <0.007
Signal to noise ratio (A-weighted), dB: 112
Damping Factor:> 1000
Input sensitivity, B: 1 - 8
Crossover modes for channels 1 - 2: HIGHPASS / FULLRANGE / BANDPASS
Crossover modes for channels 3 - 4: HIGHPASS / FULLRANGE / BANDPASS
High Pass Filter for channels 1 - 2: 15 - 4000 Hz, 12 dB / oct.
High Pass Filter for channels 3 - 4: 15 - 4000 Hz, 12 dB / oct.
Low pass filter for channels 1 - 2: 15 - 4000 Hz, 12 dB / oct.
Low pass filter for channels 3 - 4: 15 - 4000 Hz, 12 dB / oct.
RCA inputs
HDM 2 slot for expansion modules
Optional SPDIF input (28 - 96 kHz) via HDM 2 slot
Mode switch operation input "2 channels / 4 channels"
Protection when the supply voltage is outside the operating range, from short-circuiting the outputs and from overheating
Supply voltage, V: 9 - 16 (maybe 5 sec. Reduction to 6 V, compatibility with Start-Stop systems)
Fuse, A: 3 x 30
Dimensions, mm: 37.1 x 430 x 240
