יצרן: Helix

מקט:

זמינות: יש במלאי

1,999.99 ₪ 1,999.99

כמות

שנה אחריות
*מלבד כל הרמקולים וסאבוופרים

:

A very powerful 64-bit digital audio processor with fixed-point math and 1.2 billion MAC operations per second.

HELIX Extension Card (HEC) expansion card slot for additional input / output modules

Smart high-level input with ADEP circuit (input protection)

Support Start / Stop function up to 6 volts

Freely adjustable signal routing with separate matrixes for line inputs, SPDIF and HEC / AUX

Temporal alignment up to 20 ms per channel, additionally reverse alignment for common-mode summation of inputs

Optimized signal paths and power to improve sound quality

Ground lift switch to isolate the ground loop

Control inputs for connecting remote control and accessories

Inputs: 6 RCA / Cinch, 6 high-level and 1 optical SPDIF

Outputs: 8 RCA / Cinch with a maximum voltage of 6 volts

Easy setup thanks to professional and user-friendly DSP software PC-Tool Version 4

Specification:

Inputs:

6 x RCA / Cinch

6 x high level

1 x optical SPDIF (12-96 kHz sampling)

1 x remote power on

Input sensitivity:

RCA / Cinch 2 - 4 Volts

High-level 3.5 - 11 Volts

Outputs:

8 x RCA / Cinch

1 x remote start (maximum 500 mA)

Output Voltage: 6 Volts

Frequency range: 10 Hz - 22000 Hz

DSP resolution: 64 bit

DSP processor speed: 295 MHz (1.2 billion MAC operations per second)

Signal converter:

ADC: BurrBrown

DAC: BurrBrown

Signal to noise ratio - digital input: 112 dB (A-weighted)

Signal-to-Noise Ratio - Analog Input: 107 dB (A-Weighted)

Harmonic Distortion (KGI + Noise) - Digital Input: <0.0008%

Harmonic Distortion Coefficient (OIG + Noise) - Analog Input: <0.002%

Cross distortion - digital input: <0.0003%

Cross Distortion - Analog Input: <0.005%

Channel interference:> 90 dB

Power supply: 9.6 - 18 Volts (possible 5 seconds. Reduction to 6 Volts)

Current consumption: <480 mA

Additional features: HEC slot, "Ground lift" switch, ADEP protection circuit, "Auto Remote" switch

Dimensions (H x W x D): 40 x 177 x 120 mm

Our opinion

The Helix DSP.2 sound processor is a necessary device for building high-quality sound in a car. It can take a signal from a standard head unit or a standard amplifier with channel-by-channel gain. It has a Toslink optical input with support for volume control. When installing the processor after an abnormal head unit, it is possible to use RCA inputs.

At the output of the processor Helix DSP.2, we have four pairs of RCA. For each of them, you can choose any cut-off frequencies above and below from 20 to 20,000 Hz in 1 Hz increments, filter quality (Butterworth, Linkwitz, Chebyshev, or Bessel) and the slope. A time correction is available for each of the 8 channels. All settings are made through user-friendly software, which is downloaded for free from the manufacturer’s website and installed on any computer running Windows.

Optionally for the Helix DSP.2 processor, you can purchase a Bluetooth module to connect a smartphone and listen to the sound from it, a USB module to listen to the sound from a smartphone via a cable. Both modules are integrated inside the processor and do not create any problems during installation. Two separate remote controls are available for external control of the processor - one is simpler and cheaper, the other is more expensive and more complicated.

In general, Helix DSP.2 is a very successful model in its price range, which has no analogues in the world. German assembly speaks of high quality and reliability of the product. Adjustment options allow you to customize any components in any audio system (in most analogs, 1-2 types of filtering are available, here there are 4 of them). Flexible system settings allow you to choose the priorities of the processor inputs, set the delay on and off to avoid claps in the system. With all this magnificence, there are practically no errors and flaws, and if they manifest themselves, they are very promptly eliminated by the manufacturer through a free update downloaded from the site.
