Brand: Helix

Product Code:

Availability: In stock

1,399.00 ₪ 1,399.00

Qty

שנה אחריות
*מלבד כל הרמקולים וסאבוופרים
Output power RMS / max.
- @ 4 Ohms 1 x 390 / 780 Watts
- @ 2 Ohms 1 x 675 / 1,350 Watts
- @ 1 Ohm 1 x 920 / 1,840 Watts
- bridged @ 4 Ohms
- bridged @ 2 Ohms
Amplifier technology Class D
Inputs 2 x RCA / Cinch
2 x Highlevel speaker input
1 x Remote In
1 x Remote control input
Input sensitivity RCA / Cinch 1 - 6 Volts
Highlevel 2.5 - 14 Volts
Input impedance RCA / Cinch 30 kOhms
Input impedance highlevel 12 Ohms
Outputs 1 x Speaker output
Output voltage RCA / Cinch
Signal converter for digital input
Frequency response 10 Hz - 250 Hz
Bass boost 0 - 12 dB / 25 Hz - 50 Hz
Highpass
Lowpass 50 Hz - 250 Hz adjustable
Bandpass 10 Hz - 250 Hz adjustable
Subsonic 10 Hz - 50 Hz adjustable
Phase 0 - 180° adjustable
Slope high- / lowpass
Slope subsonic / lowpass Butterworth 12 dB/Oct.
Signal-to-noise ratio digital input
Signal-to-noise ratio analog input 95 dB (A-weighted)
Distortion (THD) 0.05 %
Damping factor 200
Operating voltage 9.6 - 16 Volts (max. 5 sec. down to 6 Volts)
Idle current 1000 mA
Fuse 3 x 40 A Maxi-fuse (APX)
Additional features Active, adjustable crossover, bass boost,  input mode switch, highlevel input with automatic turn on function and Advanced Diagnostics Error Protection (ADEP), Start-Stop capability, bass volume remote control
Dimensions (H x W x D) 57 x 334 x 241 mm /
2.24 x 13.15 x 9.50”
