| Output power RMS / max. |
|
| - @ 4 Ohms |
6 x 100 / 200 Watts |
| - @ 2 Ohms |
6 x 100 / 200 Watts |
| - @ 1 Ohm |
- |
| - bridged @ 4 Ohms |
3 x 200 / 400 Watts |
| - bridged @ 2 Ohms |
- |
| Max. output power per channel* |
Up to 130 Watts RMS @ 2 Ohms |
| Amplifier technology |
Class D |
| Inputs |
6 x RCA / Cinch
1 x Remote In |
| Input sensitivity |
RCA / Cinch 0.5 - 6 Volts |
| Input impedance RCA / Cinch |
20 kOhms |
| Input impedance highlevel |
- |
| Outputs |
6 x Speaker output |
| Output voltage RCA / Cinch |
- |
| Signal converter for digital input |
- |
| Frequency response |
10 Hz - 30,000 Hz |
| Bass boost |
- |
| Highpass |
15 Hz - 4,000 Hz adjustable |
| Lowpass |
40 Hz - 4,000 Hz adjustable |
| Bandpass |
15 Hz - 4,000 Hz adjustable |
Subsonic / HPF
|
15 Hz - 4,000 Hz adjustable |
| Phase |
- |
| Slope high- / lowpass |
12 dB/Oct. |
| Slope subsonic / lowpass |
- |
| Signal-to-noise ratio digital input |
- |
| Signal-to-noise ratio analog input |
98 dB (A-weighted) |
| Distortion (THD) |
0.05 % |
| Damping factor |
100 |
| Operating voltage |
10.5 - 16 Volts (max. 5 sec. down to 6 Volts) |
| Idle current |
1,550 mA |
| Fuse |
2 x 35 A Maxi-fuse (APX) |
| Additional features |
Active, adjustable crossover, subsonic input mode switch channel E / F, subsonic, Start-Stop capability |
| Dimensions (H x W x D) |
50 x 320 x 154 mm /
2.00 x 12.60 x 6.06” |
