ono amplifier with a sober design built
 with top quality component:
- Only PTH components is used (no SMD)
- No operational amplifiers on the audio path
- Nichicon/Panasonic Electrolytic Capacitors 105° low ESR
- MUNDORF and MUSE capacitors
- Silver Mica capacitors on compensation and bypass
- ATE power resistors on the signal
- Toshiba BJT
- Full cascode tecnology

Circut topology (class) A/B
Supply topology Stabilized
Power @ 4 Ohm 150W
Power @ 2 Ohm 280W
Power @ 4 Ohm (Bridge) ND
Input sensivity 1-6 Vrms
S/N ratio >110dB
THD+N @ 1KHz <0,02%
Damping factor >150
Efficiency >65%
Frequency response @ 10 Watt 10-150000Hz
Input impedanceIdle current >15K
Idle current 0.8A
Standby current < 1 mA
Visual indicator LED
Thermal protection 85° (+/- 5%)
DC protection Yes
Short circut protection Yes
FUSE (internal) 30A
Voltage operation 10.5-15.5V
Current draw @ 4 Ohm 19A)
Cooling Air Convection
