BO 12
10 channel DSP Processor & Amplifier
Specifications :
Output power: - @ 4 Ohms: 4 x 50W + 4 x 100W+2x200W（Bridged:300W）
Amplifier technology: Class AB +Class D
Bluetooth 5.0 + Optical Digital input
10 x High level speaker input
High level 5 - 10 Volts
Input impedance high level: 18 Ohms and ESR Tech
Outputs: 10 x Speaker output
Outputs: 12 x RCA line output
Output voltage: RCA 6.5 Volts RMS
Frequency response: 10 Hz - 44,000 Hz
DSP resolution: 32 Bit
Sampling rate: 44.1-192 kHz
Signal-to-noise ration analog input: 100 dB (A-weighted)
Distortion (THD): < 0,05 %
Damping factor: > 100
Operating voltage 9 - 16 Volts
Dimension: 217 x 220 x 47mm
