Power RMS (4 Ohms), W: 4 x 90 + 1 x 250
Power RMS (2 Ohms), W: 4 x 180 + 1 x 350
RMS power (4 Ohms / bridge), W: 2 x 360 + 1 x 360
Frequency range (± 1 dB), Hz: 10 - 22000
OIG + noise,%: <0.5
Signal to noise ratio, dB:> 85
Channel separation, dB: 50
Input sensitivity, V: 0.22 - 6
Modes of crossover channels 1-2: HPF / Full
Modes of crossover channels 3-4: HPF / Full
Modes of crossover channel 5: LPF
Filter HF channels 1-2: 80 - 3000 Hz
Filter HF channels 3-4: 80 - 3000 Hz
Channel low-pass filter 5: 20 - 250 Hz
Channel 5 bass boost, dB: 0 ... + 12
RCA inputs
High level inputs
Built-in Bluetooth module For streaming audio
Remote control bass level
The mode switch operation input "2/4/5 channels"
Power supply, V: 12
Fuse, A: 90 (external)
Sizes, mm: 300 x 160 x 52
